One-Stop Complete Diagnostic Scanner

Highlights of MaxiCOM MK808S

√ 2024 NEW VERSION OF MX808 MK808, SAME AS MK808BT PRO
Autel has upgraded the MK808 to the 2024 MK808S. With the same cost, you are experiencing 5X faster diagnostics and 150 wider car coverage from 1996-2023-2024. Function as MK808BT PRO MK808K-BT MK808Z-BT, the pro-level MK808S enjoys powerful CPU ROCKCHIP RK3566, improved Android 11, larger 4+64GB, 5G & 2.4 GHz Dual WiFi, newly added Wi-Fi Print, Bi-directional Control and FCA Autoauth for Chrysler Jeep Dodge Fiat etc.

√ BI-DIRECTIONAL CONTROL
As the 2024 upgraded version of Autel MaxiCOM MK808, MK808S car diagnostic scanner for all cars inherits the powerful Bi-directional Control which makes MK808S the most cost-effective Autel scanner (Cost less $300 than other bidirectional scanners). Active test/Bi-directional Control is widely used on car subsystems to help you check if the car actuators are all in good condition. Such as windows, rear mirrors, sunroof, wipers...

√ 38+ MOST POPULAR SERVICE FUNCTIONS
Autel versatile OBDII scanenr MK808S, which supports 150+ car brands & FCA AutoAuth, is an ideal choice for car repair shop owners and professional mechanics. Like the OBD2 code reader MaxiCOM MK808BT, MK808S also gets advanced 36+ hot services including Oil Reset, SAS Calibration, IMMO Keys (disable lost keys, add new keys), ABS Bleeding, Injector Coding, Battery Registration, etc., and still growing. Ranks top in professional automotive tablets.

√ DIAGNOSE ALL AVAILABLE MODULES
Same as the Snap-on code readers & scan tools, MK808S automotive diagnostic tool with reset works well on 150+ car makes and models worldwide (1996 and newer) to read/ clear codes, read E~CU info., view Live Data, do active tests, and perform special functions for all available systems. The detailed report reveals the exact nature of the problem, with possible fixes to help greatly plan the budget for repairs.

√ IMMO KEYS
Car computer diagnostic tool MK808S is cost-effective with a nice price tag of $449 considering the IMMO feature that it offers. Each time you lose the key, key reprogramming tool MK808S can add the new key and remotely disable the lost one. *ONLY available for Asian vehicles with low-grade anti-theft systems.

√ Runs Fast & AUTOVIN
Based on the MK808, the 2023 MK808S professional auto scan tool MK808S has upgraded its hardware with: ROCKCHIP RK3566 CPU, Android 11 OS, 4G RAM, 5GHz Wi-Fi, etc. to bring you faster diagnosis and operation. Unlike the MaxiCheck MX808, MK808S for all vehicles has no IP restrictions. Designed with Auto VIN, escaner automotriz professional MK808S can directly get detailed info about the car, ranging from engine type to where it was manufactured via a single touch.

Why Upgraded the MK808 to the MK808S?

For the benefit of consumers, we upgraded the MK808 to MK808S without extra cost (still cost the same), but added more features & car models.

√ Upgrade Android 4.4.4 version to Android 11.0 OS: Enhancing 5x Faster diagnostic speed than ever.

√ Maximize 1+64GB to 4+64GB Memory: Expanded memory effectively avoids lag and delay when processing multitasking.

√ Renewed CPU from ROCKCHIP RK3188 to RK3566: Optimizing the diagnostic Apps operation and bringing fast AI computing power.

√ Dual WiFi (2.4 & 5.0GHz): Accelerating the rate of diagnostic data transmission and collection.

√ 7” Touchscreen with 1024*600 Resolution: Portable size for intuitive and comfortable experience.

Detailed Information about MK808S

1.Bi-Directional Control (Active Test)

You can figure out whether a specific subsystem or component in your car functions well or not by using this tool to make the tester outputs function instead of checking in ignition status.

Click the "Update" icon to upgrade the MK808 system version to V2.62 or above to get all new features.

2. Support MV105/MV108 Inspection Camera

Autel 105 108 MaxiVideo Inspection Video Scope is compatible with MK808, maximizing the potential of MK808 to examine and clean difficult-to-reach car areas, such as spark plug holes, engine cylinders, and other small parts, quickly and safely.

Note:MV105/MV108 need to buy separately.

3.More Language optional

English, German, Spanish,Japanese,Portuguese, Dutch, French, Italian.Korean, Russian ,Polish,Swedish,Persian,Turkish,Thai,Vietnamese,Hebrew,Arabic,Indonesian

After you get the product, please tell us your SN of machine to activate the language you need .
The SN can be located on the back of the device’s body or in the following menu path “Maxisys-> Settings -> About Us”

4.38 Service Functions

Autel versatile OBDII scanenr MK808S, which supports 150+ car brands & FCA AutoAuth, is an ideal choice for car repair shop owners and professional mechanics.

Oil Reset Service

Performs reset for the Engine Oil Life system, which calculates an optimal oil life change interval depending on the vehicle driving conditions and climate, and turns off the warning light;

Electronic Parking Brake (EPB) Service

Maintains the electronic braking system safely and effectively through deactivating and activating the brake control system, assisting with brake fluid control, opening and closing brake pads, and setting brakes after disc or pad replacement, etc.

Steering Angle Sensor (SAS) Service

Performs calibration for the Steering Angle Sensor (SAS), which permanently stores the current steering wheel position as the straight-ahead position in the steering angle sensor EEPROM. On successful completion of the calibration, the steering angle sensor fault memory is automatically cleared.

Tire Pressure Monitor System (TPMS) Service

The TPMS service function include displaying sensor IDs from the vehicle’s ECU, inputting TPMS sensor replacement IDs and testing sensors

DPF Service

carry out numerous functions to the Diesel Particulate Filter system. The tool will manage DPF regeneration, DPF component replacement teach-in and DPF teach-in after replacing the engine control unit.

BMS Reset

Re-match the control module and motoring sensor for battery detecting more accurately, clear original low battery information and prevent the related control module from detecting false information.

IMMO Service

enables you to disable the lost vehicle keys and program a replacement key fob.

ABS Bleeding

ABS brake bleeding to get a firm brake pad after air exhaustion.

Throttle Matching

to initialize the throttle actuators to the default state for regulating throttle (or idle engine) operations accurately

Injector Coding

to make the cylinder better identify injector after ECU or injector is replaced.

Suspension

Seats

Lang Change

Trans adaption

TEC learn

Headlamp

CHG Tire Size

WIN DR ROOF

Note:

Please also know that Not All service & Special functions are universally compatible. Please send VIN number and the functions you need to us to check compatibility.

5.FCA Auto Auth

Since 2023, Autel has released FCA Auto Auth Function for FREE on 2018 and newer FCA cars (Chrysler, Dodge, Jeep, Fiat) in the US, Canada and Mexico, which covers wider vehicles and helps technicians win more business.

There are 3 EASY STEP:

1.Authorized OEM Access Account Registration;

2.Confirm Compatible Diagnostic Platform;

3.Immediate Authorized Secure Gateway Access.

Please remember to update FCA vehicle software to V9.50.

6.In-depth All System Diagnostics

The Diagnostics application enables a data link to the electronic control system of the test vehicle for vehicle diagnosis. The application performs functional tests, retrieves vehicle diagnostic information such as trouble and event codes and live data for various vehicle control systems, such as ABS, SRS, Engine, Transmission, Brake System, Emission System, Fuel system, Light system, Wiper System etc.

7.2 options available when accessing the Diagnosis section

1. Auto Scan –The Auto Scan function performs a comprehensive scanning of the ECUs in the vehicle’s system to locate and retrieve DTCs.

2. Control Units – displays a selection menu of all available control units of the test vehicle.

8.4 methods for Vehicle Identification

1.Auto VIN Scan

The MaxiCOM diagnostic system features the latest VIN-Based Auto VIN Scan function to identify vehicles and scan all the diagnosable ECUs and run diagnostics on the selected system.

2.Manual VIN Input

For vehicles not supporting the Auto VIN Scan function, you may manually enter the vehicle VIN.

3.Automatic Selection

The Auto VIN Scan can be selected after selecting the test vehicle manufacturer.

4.Manual Selection

When the vehicle's VIN is not automatically retrievable through the vehicle's ECU, or the specific VIN is unknown, the vehicle can be manually selected.

Note:

Auto VIN function can NOT work on all cars. You can always navigate your vehicle through the menu manually to perform diagnostics and services.

9. ECU Information

ECU Information – retrieves and displays the specific information for the tested control unit, including unit type, version numbers and other specifications.

10. Read Codes

Read Codes – displays detailed information of DTC records retrieved from the test vehicle’s ECU. On some vehicles, freeze frame data can also be retrieved for viewing.

11.Erase Codes

Erase Codes – erases DTC records and other data from the test vehicle’s ECU.

12. Live Data

Live Data – retrieves and displays live data and parameters from the test vehicle’s ECU.Display live data in text, graph & analog for easy data review.

13. Complete OBD2 functions

Reading Codes: Show the detailed description of the Diagnostic Trouble Code (DTCs)
Erasing Codes & Reset: Turns off Check Engine Light (MIL), clears codes and resets monitors.
Data Stream: Reads and displays live ECU/PCM data stream, plotting functions graphically and stores freeze frame data.
I/M Readiness Status: Shows whether the various emissions-related systems on the vehicle are operating properly and are ready for inspection and maintenance testing.
Read Live Data Stream: Show the information of continuous data stream from a vehicle in live graphic (waveform) display.
View Freeze Frame Data: Check the certain vehicle conditions which are recorded by the on-board computer at the time the emission-related fault occurs.
O2 Sensor Test: Allows retrieval and viewing of O2 sensor monitor test results for the most recently performed tests from the vehicle’s on-board computer.
On-Board Monitor Test: Retrieves and displays test results for emission-related powertrain components and systems.
Read Vehicle Information: Display the information such as VIN (Vehicle Identification Number), CID (Calibration ID) and CVN (Calibration verification number), etc.
Component Test: Certain vehicle components can be actuated by commands sent from the scanner to test their operability.

14. Additional Features

Battery Test & Electrical System Analysis ( Work with BT506 ):

Autel automotive battery test tool BT506 can test all 6V and 12V 100-2000CCA batteries including the most regular Flooded, AGM, AGM Spiral, EFB and GEL batteries. It can perform in-vehicle & out-of-vehicle tests to determine the health status of the battery, the starter, and the generator respectively.

Work with Autel MV108 HD Inspection Camera:

Turn your MaxiCOM MK808S into a video inspection scope, allowing you to examine difficult-to-reach areas normally hidden from sight. It is capable of recording digital still images and videos.

Autel Cloud Management :

Device Management & Report Management, allow you to upload data or diagnostic reports to Autel Cloud without loss and share reports with customers through QR Code/ email/ text message easily.

Note:

BT506 and MV108 is NOT included in the package of Mk808S.
Functions NOT universal, please send VIN(17 digits),car makes, model, year to check compatibility before purchase.

NOTE: MK808S can add new keys on low anti-theft grade vehicles only. It can not add keys on high anti-theft grade vehicles like on BMW, Benz, Audi, VW and etc. If you want professional IMMO Key product, please consider Autel KM100/IM508/IM608 PRO/IM608 II.

15. 99% of Vehicle Coverage

Autel Scanner MK808S can work on 80+ Vehicle Makes and Models of American, European and Asian, covering 10,000+ cars, some of the 2023 latest car models.

- Europe:

Benz, Sprinter, BMW, Fiat, LandRover, Maserati, Opel, Peugeot, Porsche, Lancia, LT3, Maybach, Mini, Seat, Skoda, Vauxhall, Volkswagen CV, Renault, Saab, Smart, Volvo, Volkswagen, Abarth, Alfa, Audi, Bentley, Bugatti, Citroen, Dacia, Ford, Jaguar, Lambor Ghini

- Asia:

Acura, Daewoo, Daihatsu, Honda, Hyundai, Infiniti, Isuzu, Kia, Lexus, Maruti Suzuki, Mazda, Mitsubishi, Nissan, SsangYong, Subaru, Suzuki, Toyota, GTR, Scion

- America:

Chrysler, Ford, GM, Dodge, Jeep

Australia: Compatible with AUST Holden, AUST Ford.

Malaysia car: Perodua，ProtonIndian car：Maruti_Suzuki，Mahindra，tata, india Datsun

These software need to pay extra money to buy：
Brazil car/Latin America car/South American car：Fiat Brazil，GM Brazil

16.Warranty & Update

*One Year Warranty for Any Quality Problems
*Lifetime Free Tech Support

*One Year Free Update.The update fee is usd125 per year.
*Lifetime free use.

17.Different Choice for Diagnoses

MK808/MK808S is suitable for most OBD2 vehicles and support many car brands like Ford, Honda, Chevrolet, Jeep, Toyota, Dodge, GM, Volkswagen, Audi, BMW, Benz, etc.
When it comes to the Non-OBD2 vehicles, you can connect the device with vehicles via adapters (not included) to complete car diagnoses, and the signal connected will be more stable. This diagnostic tool support different kinds of adapter connection.

18.Package List

1.Main unit
2. USB External Power Adapter
3. Main cable
4. Quick Reference Guide
5. Carry case
6. Mini USB Cable

19. Q&A

Q: If it is original?

A: We are only one Autel official store on Aliexpress.Other store are not the official store.

Q: If it is global version?

A: MK808/MK808S is global version.But for some local software,you need to pay extra money to buy it.Please contact with us regarding the details.

Q:How do I know if the MK808S supports my car?

A:You can check the link:

https://www.autel.com/vehicle-coverage/coverage2

Or contact with us to confirm.
